| Hardware Specifications |
| CPU |
64-bit Quad-core ARM Cortex-A76 @ 2.4GHz |
| AI Accelerator |
Hailo-8L (13 TOPS) |
| GPU |
Broadcom VideoCore VII |
| Internal Storage |
1TB NVMe SSD |
| Memory |
8GB SDRAM |
| Networking Interface |
1 × 10/100/1000T Gigabit Ethernet (RJ45) |
| Button |
> 10 sec: system shutdown |
| USB Port |
2 x USB 3.0 ports
2 x USB 2.0 ports |
| Operating Temperature |
0 to 50 degrees C |
| Power Interface |
USB Type-C power input |
| Power Input |
5V/5A DC via USB Type-C power connector |
| Power Consumption |
Max. 27W |
| Enclosure |
Metal enclosure |
| Installation |
Desktop and wall-mount |
| Dimensions (W × D × H) |
88.7 × 68.2 × 41 mm |
| Weight |
0.287 kg |
| Camera and NVR Compatibility |
| Camera Compatibility |
RTSP IP camera support |
| Max. Channels |
8-channel IP cameras |
| NVR |
Built-in video recording capability |
| AI Function |
| Parking Detection |
Illegal Vehicle Intrusion / Idle Timeout Detection |
| Human Detection |
Line Crossing / Area Intrusion / Crowd Counting |
| Pet Detection |
Cats & Dogs |
| Face Recognition |
Whitelist / Blacklist |
| Industrial Safety Detection |
Helmet / Vest |
| Fire & Smoke Detection |
Fire & Smoke |
| Smart Search System |
Object Filtering / Area Detection / Feature Matching (Human / Vehicle / Pet) / Vehicle Attribute Search (e.g., color, type) / Interactive Search Enhancement (LLM-based concept) |
| Management Functions |
| Management Interface |
HTTP |
| System Management |
AI parameter configuration
Camera IP/device name configuration
Camera event parameter configuration
Firmware upgrade by HTTP protocol through Ethernet network Configuration upload/download through HTTP
NTP
System reboot |
| System Monitoring |
CPU/RAM/GPU utilization monitoring
Export logs and error reports |
| AI Model Management |
AI model upload/update interface
Model version rollback |
| Event Management |
Event/alarm condition configuration
Trigger actions (notification/recording) |
| Real-time Display |
Homepage real-time event display
Event details with live video stream
Incident processing record window |
| Playback |
Event log playback
Event replay |
| Monitoring View |
Multi-camera NVR-style interface
Multi-screen / single-screen switching
Historical person-fragment search |
| Intelligent Platform |
Search-based playback query interface
Integrated homepage search optimization |
| Historical Data |
Historical event record query
Report generation |
| User Management |
Permission control |
| Video Compression |
H.264 / H.265
H.264+ / H.265+ |
| Video Streaming |
RTSP (Sub-stream only)*
Resolution: Up to 704 × 576 (D1)
Frame Rate: Up to 10 fps
Compression: H.264 / H.265 / H.265+ (H.265+ supported for optimized streaming) |
| Recording Performance |
8-channel simultaneous recording
Up to 1080P Full HD recording @ 25/30 fps (per channel)
Supports 960P / 720P / D1 |
| *RTSP stream is based on sub-stream for bandwidth-efficient preview and system integration. |
