| Camera |
| Image Sensor |
1/2.8" 5 megapixel SONY STARVIS Back-illuminated Progressive Scan CMOS sensor |
| Lens |
Focus Length: 2.7-13.5mm
Focus Control: Auto
Lens Type: Auto
Angle of view:
Horizontal: 29~103 degrees
Vertical: 16~54 degrees |
| Min. Illumination |
0.006 lux (color) @ F1.6
0lux (B/W) @ IR on |
| IR Illuminations |
Built-in smart IR illuminators, effective up to 50 meters
Built-in 4000K warm white LED, effective up to 40 meters
*The IR distance is based on the environment |
| Effective Pixels (H x V) |
2616 x 1964 |
| Image |
| Video Compression |
H.264(+)/H.265(+)/JPEG/AVI |
| Video Resolution |
| Protocol | Main Stream | Sub Stream | H.264/H.264+ H.265/H.265+
| 2592 x 19440@30fps 2560 x 1440@30fps 1920 x 1080@30fps 1280 x 720@30fps | 1280 x 720@30fps 720 x 480@30fps
| | JPEG | 1920 x 1080@30fps |
|
| Protocol |
Main Stream |
| H.264/H.264+H.265/H.265+ |
2592 x 19440@30fps 2560 x 1440@30fps 1920 x 1080@30fps 1280 x 720@30fps |
| JPEG |
1920 x 1080@30fps |
| Frame Rate |
Up to 30 fps for all resolutions |
| Bitrate |
32~16384kbps |
| Shutter Time |
Auto: 1/30-1/100000Sec |
| Image Setting |
AFFocus
Image adjustment
Exposure settings
Day and Night Mode
White Balance
Video Adjustment
Image Enhancement
Backlight Settings
OSD settings
Privacy Mask
ROI(Region of Interest) |
| Streaming |
Streaming over UDP, TCP, HTTP, or HTTPS
Controllable frame rate
Constant and variable bit rate |
| Audio |
| Audio Input |
External audio I/O |
| Audio Streaming |
Two-way audio |
| Audio Compression |
G.711A/G.711U/AAC/MP2L2 |
| Networking & Configuration |
| Standards Compliance |
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3af/at Power over Ethernet |
| Protocol |
TCP/IP,IPv4/v6, ICMP, HTTP, HTTPS, FTP, DHCP, PLANET DDNS, Easy DDNS, RTP, RTSP, RTCP, PPPoE, NTP, SMTP, UDP, QoS, 802.1X, P2P, IPEYE, Cloud |
| Security |
User Management options for various authorities
Admin
Operator
Guest |
| Users |
On-line monitoring of 16 clients at the same time |
| Web Brower |
Microsoft IE8-11, Edge, Google Chrome, Firefox |
| App |
Yes (Android, IOS with P2P QR code) |
| Language |
Chinese Simplified, Chinese Traditional, English, Bulgarian, Polish, Arabic, German, Russian, French, Korean, Portuguese, Japanese, Turkish, Spanish, Hebrew, Italian, Nederlands,Czech, Vietnamese |
| System Integration |
| Application Programming Interface |
ONVIF compliant |
| Alarm Triggering |
Motion Detection, Privacy Mask, Video Tampering, ROI, Intrusion Detection, Line Cross Detection, Loitering Detection, People Gathering Detection, Enter/Leave Area |
| Alarm Events |
SMTP, FTP, Cloud (Google), Light |
| Hardware Specifications |
| Power Requirements |
12V DC, 0.95A
IEEE 802.3af/at Power over Ethernet |
| Power Consumption |
6.6W (IR on)
7.2W (white LED on) |
| Dimensions (W x D x H) |
268 x 95 x 88 mm |
| Weight |
1.5kg |
| Reset Button |
on the bottom of camera (next to SD slot) |
| SD Card Slot |
Micro SD (1TB maximum) |
| LED |
IR : 38μ x 4pcs Warm LED : 38μ x 4pcs 4000K |
| Connector |
10/100Mbps Ethernet, waterproof/dustproof RJ45 connector
DC power jack
RCA audio in/out (white) |
| Enclosure |
IP67 metal case |
| Power over Ethernet |
| PoE Standard |
IEEE 802.3af/at PoE PD |
| Standards Conformance |
| Regulatory Compliance |
FCC Part 15 Class B, CE |
| NDAA Compliance |
Yes |
| Environment |
| Operating |
Temperature: -20 ~ 60 degrees C
Relative Humidity: 5 ~ 95% (non-condensing) |
| Storage |
Temperature: -20 ~ 60 degrees C
Relative Humidity: 5 ~ 95% (non-condensing) |
