| Hardware |
| Number of Ports |
8 D-sub ports (15-pin) |
| Maximum Control of PCs |
64 by 2-tier star-type cascading (KVM-210-08 x 8) |
| PC Ports |
| Keyboard: | PS/2 female + USB type A female | | Mouse: | PS/2 female + USB type A female | | Video: | 8 D-sub ports (15 female) |
|
| Keyboard: |
PS/2 female + USB type A female |
| Mouse: |
PS/2 female + USB type A female |
| Video: |
8 D-sub ports (15 female) |
| Console Ports |
| Keyboard: | PS/2 female + USB type A female | | Mouse: | PS/2 female + USB type A female | | Video: | 1 D-sub port (15 female) | |
| Keyboard: |
PS/2 female + USB type A female |
| Mouse: |
PS/2 female + USB type A female |
| Video: |
1 D-sub port (15 female) |
| LED |
| On Line: | 8 (Red) | | Selected: | 8 (Green) | |
| On Line: |
8 (Red) |
| Selected: |
8 (Green) |
| Button |
| Reset: | 1 reset button | | Select: | 8 select buttons | |
| Reset: |
1 reset button |
| Select: |
8 select buttons |
| Remote Console |
1 RJ45 port for 10/100/1000BASE-T |
| Video Resolution |
Local side: 2048 x 1536 (max)
Remote side: 1920 x 1080 (max)
|
| Housing |
Metal |
| Dimensions (W x D x H) |
432 x 155 x 44 mm |
| Weight |
2.22kg |
| Power Requirement |
9V DC, 1A |
| Installation |
1U rack-mountable, desktop |
| Management |
| Supported Protocol |
TCP, IP, HTTP |
| Client Software |
IPKVM Software |
| PC Selection |
Port select button
Hotkeys on keyboard
OSD (on screen display)
|
| Scan Interval |
5~60 seconds |
| Security |
User password and super password
DES, AES and 3DES
|
| Environment & Certification |
| Operating Temperature |
-10 ~ 50 degrees C |
| Storage Temperature |
-20 ~ 60 degrees C |
| Operating Humidity |
0 ~ 90% |
| Regulatory |
CE, FCC |
