| Hardware |
| Number of Ports |
8 |
| Maximum |
64 by cascading (KVM-210-08 x 8) |
| PC Ports |
| Keyboard: | PS/2 female + USB Type A female | | Mouse: | PS/2 female + USB Type A female | | Video: | 8 x HDB-15 female |
|
| Keyboard: |
PS/2 female + USB Type A female |
| Mouse: |
PS/2 female + USB Type A female |
| Video: |
8 x HDB-15 female |
| Console Ports |
| Keyboard: | PS/2 female + USB Type A female | | Mouse: | PS/2 female + USB Type A female | | Video: | 1 x HDB-15 female | |
| Keyboard: |
PS/2 female + USB Type A female |
| Mouse: |
PS/2 female + USB Type A female |
| Video: |
1 x HDB-15 female |
| LED |
|
| On Line: |
8 |
| Selected: |
8 |
| Button |
|
| Reset: |
1 |
| Select: |
8 |
| Video Resolution |
2048 x 1536 |
| Housing |
Metal |
| Dimensions (W x D x H) |
432 x 155 x 44 mm |
| Weight |
2.22kg |
| Power Requirement |
9V DC, 1A |
| Installation |
1U rack-mountable, desktop |
| Management |
| PC Selection |
Port select button
Hotkeys on keyboard
OSD (on screen display)
|
| Scan Interval |
5~60 seconds |
| Security |
User password and super password |
| Environment & Certification |
| Operating Temperature |
-10 ~ 50 degrees C |
| Operating Humidity |
0 ~ 90% |
| Regulatory |
CE, FCC |
