| Product |
| Protocol |
IEEE 802.3, 10BASE-T
IEEE 802.3u, 100BASE-TX
IEEE 802.3u, 100BASE-FX |
| Dimensions (W x D x H) |
97 x 69 x 26 mm |
| Weight |
0.2kg |
| Power Input |
5V DC, 2A, max. |
| Power Supply |
AC Adapter 100-240VAC Frequency: 50-60Hz |
| Enclosure |
Compact-sized metal housing
Case with anticorrosion treatment
Electrostatic paint |
| Connectors and Cables |
| Shielded Twisted-pair |
RJ45, Category 5 (EIA/TIA 568) |
| Fiber-optic |
FT-801 : ST / Multi-mode / 2km
FT-802 : SC / Multi-mode / 2km
FT-803: MTRJ / Multi-mode / 2km
FT-802S15 : SC / Single mode / 15km
FT-802S35 : SC / Single mode / 35km
FT-802S50 : SC / Single mode / 50km
FT-806A20: WDM SC / Single mode / 20km
FT-806B20: WDM SC / Single mode / 20km
FT-806A60: WDM SC / Single mode / 60km
FT-806B60: WDM SC / Single mode / 60km |
| Multi-mode Cable |
50/125, 62.5/125 m |
| Single-mode (SM) Cable |
9/125 m |
| Optic Wavelength |
FT-801: 1310nm
FT-802: 1310nm
FT-803: 1310nm
FT-802S15: 1310nm
FT-802S35: 1310nm
FT-802S50: 1310nm
FT-806A20: TX: 1310nm; RX: 1550nm
FT-806B20: TX: 1550nm; RX: 1310nm
FT-806A60: TX: 1310nm; RX: 1550nm
FT-806B60: TX: 1550nm; RX: 1310nm |
| Max. Launch Power (dBm) |
FT-801: -14
FT-802: -14
FT-803: -14
FT-802S15:0
FT-802S35:-8
FT-802S50:0
FT-806A20:-8
FT-806B20:-8
FT-806A60:0
FT-806B60:0 |
| Min. Launch Power (dBm) |
FT-801: -20 (62.5/125m), -23.5 (50/125m)
FT-802: -20 (62.5/125m), -23.5 (50/125m)
FT-803: -20 (62.5/125m), -23.5 (50/125m)
FT-802S15: ?20
FT-802S35: -15
FT-802S50:-5
FT-806A20:-14
FT-806B20:-14
FT-806A60:-5
FT-806B60:-5 |
| Receive Sensitivity (dBm) |
FT-801: -31.8
FT-802: -31.8
FT-803: -31.8
FT-802S15: -32
FT-802S35:-34
FT-802S50: -35
FT-806A20:-31
FT-806B20:-31
FT-806A60:-34
FT-806B60:-34 |
| Maximum Input Power (dBm) |
FT-801: -14
FT-802: -14
FT-803: -14
FT-802S15:0
FT-802S35:0
FT-802S50:0
FT-806A20:0
FT-806B20:0
FT-806A60:0
FT-806B60:0 |
| Supported Distances and Functions |
| Shielded Twisted-pair |
100m (328 ft.) |
| Multi-mode Fiber Optic |
412m (1,350 ft.) (half-duplex)
2km (1.2 miles) (full-duplex) |
| Single-mode (SM) |
412m (1,350 ft.) (half-duplex)
15km (9 miles) (full-duplex)
20km (12 miles) (full-duplex)
35km (21 miles) (full-duplex)
50km (31 miles) (full-duplex)
60km (37 miles) (full-duplex) |
| Port Mode |
TP: Half and full duplex, auto-negotiation
FX: Half and full duplex via DIP switch |
| Environment & Emissions |
| Operating Environment |
Temperature: 0~50 degrees C
Humidity: 5~90% non-condensing |
| Storage Environment |
Temperature: -40~70 degrees C
Humidity: 5~90% non-condensing |
| Emissions |
FCC Class A, CE Class A |
