| 硬件规格 |
| 国际标准 |
IEEE 802.3, 10Base-T
IEEE 802.3u, 100Base-TX
IEEE 802.3ab, 1000Base-T
IEEE 802.3z, 1000Base-SX/LX
IEEE 802.3ah OAM
|
| 端口 |
1 x 10/100/1000Base-T port
1 x 1000Base-SX/LX port
|
| 电口 |
RJ-45 port (Auto-MDI/MDI-X) Twisted Pair |
| 光纤接口 |
GST-802 / GST-802S: SC
GST-805A: SFP
GST-806A15 / GST-806B15 / GST-806A60 / GST-806B60: WDM |
| 光学波长 |
GST-802: 850nm
GST-802S: 1310nm
GST-805A: N/A
GST-806A15: TX:1310nm / RX:1550nm
GST-806B15: TX:1550nm / RX:1310nm
GST-806A60: TX:1310nm / RX:1550nm
GST-806B60: TX:1550nm / RX:1310nm
|
| 最大发射功率（dBm） |
GST-802: -4 dBm
GST-802S: -3 dBm
GST-805A: N/A
GST-806A15: -3 dBm
GST-806B15: +5 dBm
GST-806A60: -3 dBm
GST-806B60: +4 dBm |
| 最小发射功率（dBm） |
GST-802: -9.5 dBm
GST-802S: -9.5dBm
GST-805A: N/A
GST-806A15: -9 dBm
GST-806B15: 0 dBm
GST-806A60: -9 dBm
GST-806B60: -1 dBm |
| 接收灵敏度 |
GST-802: -13.5 dBm
GST-802S: -14.4 dBm
GST-805A: N/A
GST-806A15: -21 dBm
GST-806B15: -25 dBm
GST-806A60: -21 dBm
GST-806B60: -25 dBm |
| 最大输入功率 |
GST-802: -18 dBm
GST-802S: -20 dBm
GST-805A: N/A
GST-806A15: -3 dBm
GST-806B15: -3 dBm
GST-806A60: -2 dBm
GST-806B60: -2 dBm |
| 高速双绞线 |
10/20Mbps for Half / Full-Duplex
100/200Mbps for Half / Full Duplex
2000Mbps for Full-Duplex
|
| 高速光纤 |
2000Mbps for Full-Duplex |
| 电缆双绞线 |
10Base-T: 2-pair UTP Cat. 3,4,5, up to 100m
100Base-TX: 2-pair UTP Cat. 5, up to 100m
1000Base-T: 4-pair STP Cat 5 up to 100m
|
| 光纤电缆 |
� 50/125?m or 62.5/125?m multi-mode fiber cable, up to 220/550m.
� 9/125?m single-mode cable, provides long distance for 10/20/30/40/50/70/120km (vary on fiber transceiver or SFP module)
|
| LED 指示灯 |
� PWR (Green)
� TP: 1000, LINK/ACT
� Fiber: LINK/ACT |
| DIP 开关 |
Fiber (Auto-negotiation / Manual), LFP (Disable / Enable) |
| 功率消耗 |
3.1 Watts / 10BTU (maximum) |
| OAM |
TS-1000, IEEE 802.3ah terminal |
| 巨型帧大小 |
9K |
| 电源输入 |
DC 5V / 2A |
| 尺寸 (W x D x H) |
81 x 94 x 26 mm |
| 操作环境 |
Temperature: 0~50 degrees C; Humidity: 5~90% non-condensing |
| 储存环境 |
Temperature: -40~70 degrees C; Humidity: 5~90% non-condensing |
| 认证 |
FCC Class A, CE Class A |
