| 硬件特性 |
| 电口 |
4个10/100Base-TX Ports |
| 光口 |
1个100Base-FX Port |
| 光纤端口类型 |
ISW-514PT?Multi-Mode
ISW-514PT15?Single Mode
ISW-514PTF?Vary on SFP |
| Connector Type |
ISW-514PT?SC
ISW-514PT15?SC
ISW-514PTF?LC |
| 最大传输距离 |
ISW-514PT?2km
ISW-514PT15?15km
ISW-514PTF?Vary on SFP |
| 光频 |
ISW-514PT?1300nm
ISW-514PT15?1310nm
ISW-514PTF?Vary on SFP |
| 发射功率(dBm) |
ISW-514PT?Max.: -14??Min.: -20
ISW-514PT15?Max.: 0??Min.: -20
ISW-514PTF?Vary on SFP
|
| 接收灵敏度 (dBm) |
ISW-514PT?-32
ISW-514PT15?-32
ISW-514PTF?Vary on SFP |
| PoE 供电端口 |
4个IEEE 802.3af PoE ports |
| 尺寸 |
135 x 87.8 x 56 mm |
| 重量 |
842g |
| LED指示灯 |
Power1, Power2 and Fault
Port 1~4: PoE in-use, LNK/ACT
Port 5: LNK/ACT
|
| 电源要求 |
24 or 48 V DC, redundant power with polarity reverse protection function |
| 安装方式 |
DIN rail kit and wall mount ear |
| 报警 |
Provides one relay output for power failure
Alarm relay current carry ability: 1A @ DC 24V
|
| 以太网供电（PoE） |
| PoE 供电标准 |
IEEE 802.3af Power over Ethernet / PSE |
| PoE 电源供电类型 |
End-Span |
| PoE 输出功率 |
Per Port 48V DC, 350mA . max. 15.4 watts |
| 供电针脚定义 |
1/2(+), 3/6(-) |
| 2层特性 |
| 处理方案 |
Store-and-Forward |
| MAC地址表 |
2K entries |
| 流量控制 |
Back pressure for half duplex
IEEE 802.3x pause frame for full duplex
|
| 交换结构 |
1Gbps |
| 带宽传输 |
0.74Mpps |
| 电缆类型 |
10/100Base-TX:
Cat. 3, 4, 5, 5e and 6 UTP cable (100meters max.)
EIA/TIA-568 100-ohm STP (100meters, max.)
|
| 标准一致性 |
| 国际标准 |
IEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3x Full-Duplex Flow Control
IEEE 802.3af Power over Ethernet
|
| 遵从法规 |
FCC Part 15 Class A, CE |
| 稳定性测试 |
IEC60068-2-32 (Free Fall)
IEC60068-2-27 (Shock)
IEC60068-2-6 (Vibration)
|
| 环境 |
| 温度 |
Operating: -40~75 degrees C
Storage: -40~85 degrees C
|
| 湿度 |
Operating: 5~90%, Storage: 5~90% (non-condensing) |
