| Hardware Specifications |
| 接口 |
输入接口 1 x RJ-45 STP
PoE (Data + Power) In
输出接口 1 x RJ-45 STP
Data Out
DC Socket DC Out
DIP-Switch 12V DC/19V DC/24V DC output voltage
|
| LED 指示灯 |
System: Power x 1 (Green) |
| 网络线缆 |
Ultra PoE (50W) 10/100/1000Base-T: 4-Pair UTP Cat. 5e, 6 up to 100m (328ft)
802.3af / at PoE (15W / 30W) 10/100/1000Base-T: 2-Pair UTP Cat. 3, 5, 5e, 6 up to 100m (328ft)
|
| 速率 |
10/100/1000Mbps |
| 外形尺寸 (W x D x H) |
95 x 70 x 26 mm |
| 重量 |
300g |
| 电源要求 |
52 ~ 56V DC |
| 电源功率 |
50 watts (maximum) |
| 工作温度 |
0 ~ 50 degrees C |
| 存储温度 |
-10 ~ 70 degrees C |
| 存储湿度 |
5 ~ 95% (Non-condensing) |
| Power over Ethernet |
| PoE 标准 |
IEEE 802.3at Power over Ethernet Plus |
| Power 输出 |
DC 12V/19V/24V by DIP switch control |
| PoE供电设备类型 |
End-Span + Mid-Span |
| 供电引脚分配 |
Pair 1: 1/2(-), 3/6(+)
Pair 2: 4/5(+), 7/8(-) |
| Standards Conformance |
| 标准一致性 |
IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100Base-TX Fast Ethernet
IEEE 802.3ab 1000Base-T Gigabit Ethernet
IEEE 802.3at High Power over Ethernet
IEEE 802.3af Power over Ethernet |
| 法规遵从 |
FCC Part 15 Class A, CE |
