| 硬件规格 |
| 附件接口 |
PCI Express Serial Bus Interface |
| 媒体接口 |
10/100/1000Base-T RJ-45 Copper Interface |
| 电缆 |
10Base-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA / TIA-568 100? STP (maximum 100m)
100Base-TX: UTP category 5, 5e cable (maximum 100m)
EIA / TIA-568 100? STP (maximum 100m)
1000Base-T: UTP category 5, 5e cable (maximum 100m)
EIA / TIA-568 100? STP (maximum 100m) |
| 巨型帧 |
9K Bytes |
| LED 指示灯 |
LNK / ACT & 1000 per port |
| 尺寸 (W x D x H) |
65 x 40 x 19 mm |
| 重量 |
32g |
| 高级功能 |
| 2层功能 |
IEEE 802.3x flow control support
IEEE 802.1Q VLAN support |
| 操作系统 |
Windows 98 / ME
Windows 2000 / 2000 / 2003 / 2003R2
Windows XP
Windows Vista
Windows 7
Windows 8
Linux / MAC OS |
| 标准 |
| 符合规定 |
FCC Part 15 Class B, CE |
| 国际标准 |
| IEEE 802.3 | 10Base-T Ethernet | | IEEE 802.3u | 100Base-TX Fast Ethernet | | IEEE 802.3ab | 1000Base-T Gigabit Ethernet | | IEEE 802.3x | Flow control and back pressure | | IEEE 802.1Q | VLAN tagging |
|
| 环境 |
| 操作 |
| Temperature: | 0 ~ 50 degrees C | | Relative Humidity: | 10 ~ 90% (non-condensing) |
|
| 储存 |
| Temperature: | -40 ~ 70 degrees C | | Relative Humidity: | 10 ~ 90% (non-condensing) |
|
